Resistance Temperature Detector

Intrinsic safety and increased safety type thermocouple and resistance temperature detector_R950 (ETR10 series)_R951, R952, R953, R954, R955, R956, R957, R958, R95A, R95B, R95C, R95D

R950 (ETR10 series)_R951, R952, R953, R954, R955, R956, R957, R958, R95A, R95B, R95C, R95D

Service intended

Measuring the temperature in the area where bustible gas, particles and flammable liquid exist can be a very dangerous task. The electrical energy of measuring instrument is lower than electric motor, however, the malfunction of the instrument or the accident can cause to start the explosion. Therefore, ETR10 series is explosion proof type product which is designed to be used in a critical danger zone (Ex e=Zone 1, Ex ia=Zone 0) by acquiring IECEx and ATEX certification.

Certificates KCS Ex e IIC T6...T1
ATEX II 2G Ex e IIC T6...T1
IECEx Ex e IIC T6...T1 Gb
KCS Ex ia IIC T6
ATEX II 1/2G Ex ia IIC T6...T3 Ga/Gb
IECEx Ex ia IIC T6...T3 Ga/Gb
CSA Ex eb IIC T6...T1 Gb

Standard features

Element

RTD : Pt 100 Ω at 0 ℃

  ATEX IECEx KCS CSA
Ex e K, E, N
Ex ia K, J, T, E, N, B, R, S K, E -
Standard nipple material 304SS (Head type only)
Standard nipple length 100 or 150 mm (Head type only)
Enclosure material Die cast aluminium (ALDC) or 316SS (Head type only)
Standard measuring material 316SS
Electrical rating 10 mA 4 VDC resistance load
Standard process connection ½" NPT
Ambient temperature -40 ~ +65 ℃ (Ex ia)
-40 ~ +65 ℃ (Ex e)
