Explosion proof type space heater_H100 series

H100 series

Service intended

Space heater is filled and compressed with Ni/Cr heat element, ceramics, and Mgo element. This product has the fixed terminal pin at both sides, therefore, maximization on the heat conduction of insulation products and the heat conductivity are possible. Basically, space heater uses tube, and it can be used in various type of conditions. Furthermore, heat element's outer frame is made of thin steel, so it can be easily modified to provide an easier installation, and its mechanical strength provides a strong performance against the temperature fluctuations. This product is also designed to protect the heat element from oxidization by providing closed ends, and it can prolong its life-cycle.

Usage Used to prevent freezing of electric motor and to maintain the temperature of specific space or area
Safety and environment This product is not designed to use the controller to control temperature. Instead, the temperature can be controlled by changing voltage (V) and wattage (W) on the space heater. Therefore, it is critical to check the voltage and the wattage indicated on the product before installation. This product is made of environment-friendly and harmless materials to human body. Please dismantle the product before discarding.
Heating element Ni-Cr (Standard)
Fe-Cr
Kantal
Tube material 304SS
Standard Explosive atmospheres. Equipment. General requirements
■ EN 60079-0:2009
Electrical apparatus for explosive gas atmospheres. Increased safety "e"
■ EN 60079-7:2007
Temperature effect Accuracy at temperature above and below the reference temperature (20℃) will be effected by approximately ±1.0% per 10℃ of full scale
Ambient temperature Tamb = -40 ~ 70 ℃
Certificates KCS Ex e II
ATEX II 2G Ex e II Gb
IECEx Ex e IIC Gb
